MISSION ADAPTIVE CHARGING STATION™ (MAX-8)

Robust, reliable charging solution that keeps missions running and operators powered up

Power management

FEATURES

THE NERV CENTR Mission Adaptive Charging Station™ (MAX-8) is an intelligent portable charging station that lets teams do more with less. The MAX-8 can charge up to 8 batteries simultaneously. It evaluates the power source and adjusts charge rates to maximize power and minimize charge times, with no special programming or configuration required.

Key Features

PLUG & PLAY ADAPTERS AVAILABLE TO SUPPORT BATTERIES FOR A WIDE VARIETY OF EQUIPMENT BATTERIES

Specifications

The MAX-8 uses smart adapter technology to prioritize charging, adjust charge rates and minimize charge times. It can draw power from multiple sources, like AC, solar and vehicle, and supports a variety of common batteries.

POWER INPUT: 1 x DC INPUT
POWER OUTPUT: 8 x OUTPUTS (2 per bay)
USB PORTS: 4 x USB A / 1.5A per port
OPERATING TEMPERATURE:
-13°F (-25°C) to 140°F (60°C)

	POWER INPUT	POWER OUTPUTS
VOLTAGE	7-55V DC	3-58V
MAX CURRENT	35A	7.5A
MAX POWER	1.1 kW	130W

WEIGHT	NO AC BRICK	WITH AC BRICK
lbs	14.4	22.6
kg	6.5	10.3

Dimensions

Product Documents

01.13.2025 Spec Sheet

01.13.2025 User guide

11.27.2024 Firmware Updates

"In my opinion, the Mission Adaptive Charging Station (MAX-8) will be an instrumental asset for future use with EOD tools and equipment. EOD personnel will continue to require the use of battery powered devices rapidly charged while conducting response operations worldwide. The fielding of the Mission Adaptive Charging Station would greatly increase their mission capabilities."

PLATOON LEADER, USMC EOD COMPANY

"With this charger, team platoon equipment loadouts are reduced and simplified... this is of significant importance to the EOD community, as teams often operate away from infrastructure and with limited equipment, but need to maintain power management."

COMPANY COMMANDER, U.S. ARMY EOD COMPANY

"The Mission Adaptive Charging Station perfectly bridged the gap between Garrison and tactical environments and is the right fit for the FOB environment, replacing a multitude of individual charging stations and streamlining the battery charging process that each EOD team executes during mission prep and reset."

COMPANY COMMANDER, U.S. ARMY EOD COMPANY

"Galvion’s MAX-8 is an extremely valuable asset to platoons in the field, as these cases allow for charging capabilities independent of company assets. The case allowing for the charging of ASIP batteries, the SoloPack batteries, and USB devices allowed for long-term sustainment of our mission capabilities and our devices, ranging from our radios to our ATAKs. Without the case, our capabilities in communications and mission readiness would have been greatly reduced. Another extremely helpful face set was the simple interface that was easy to use and short percentages of battery charge unlike our conventional chargers."

CAPTAIN, GEORGIA ARMY NATIONAL GUARD, BRAVO COMPANY
